Durable ABS casing with a glass panel.
• 1024×600 HD touchscreen display.
• Batch configuration and transfer.
• Remote and one-touch unlocking of linked door stations.
• Network camera monitoring and security alarm.
Hardware Specification
Screen
7-inch ultra-thin TFT LCD screen
Screen Resolution
1024×600
Operation System
Linux
Power Consumption
＜10W
Audio Quality
Noise suppression,echo cancellation and AGC
Audio Input
1 built-in omnidirectional microphone
Audio Output
1 built-in speaker
Audio Compression Standard
MP3 G711
Audio Compression Bitrate
128Kbps
Power Supply
DC12V±25%,IEEE802.3af, Standard PoE
Weight
360g
Network
100Mbps network port, supports IEEE802.3af PoE power supply,WIFI4、2.4GHZ
Interface
Power*1, network*1, WiFi*1,RS485*1, IO output*2, IO input*8, TF card slot*1
Dimensions (L x W x H)
193mm×143mm×25mm
Operating Environment
-10°C to +55°C, 10% to 90%, non-condensing, indoor
Basic Business
Protocol
Private protocol
Network protocol
TCP/IP, IPv4, HTTP, RTP, RTSP, NTP
Specification Index
Capacity
200 ScreenShots
200 Zone Alarms
A total of 20 connected devices, including IPCs, entrance stations, NVRs (up to 2), and Doorbells
Linked Indoor Station Capacity
19 extensions
Compliance
NDAA Compliant
