• Front panel: Aluminum alloy
• Supports batch configuration
• Supports call and intercom with the connected indoor stations and Guard Live.
• Supports monitoring functions, security alarm, tamper alarm
• Supports Wi-Fi
• Built-in IC card reader

Hardware Specification
Supplement Light
IR light(Adaptive infrared compensation)
FOV
Horizontal:124.3°
Vertical:67.5°
Diagonal:147.2°
Power Consumption
＜10W
Volume Adjustment
Adjustable
Audio Quality
Noise suppression, echo cancellation and AGC
Audio Input
1 built-in omnidirectional microphone
Audio Output
1 built-in speaker
Audio Compression Standard
PCM, G711, MP3
Audio Compression Bitrate
128Kbps
Protection Level
IP65 (Apply waterproof glue to the gap between the device and the wall. For more information, see the quick guide.)
IK08
Power Supply
DC 12V±25% input;IEEE802.3af, Standard PoE
Operating System
Linux
Weight
0.267Kg
Mount Method
Wall mounted, flush installation
Network
100Mbps network port, supports IEEE802.3af PoE power supply，WIFI
Interface
Power *1, network port *1, RS485, door lock interface *2, IO input *4
Resolution
2MP
Dimensions (L x W x H)
79mm×171mm×34mm
Operating Environment
﹣30℃~﹢60℃,10%～90%, non-condensing, outdoor
Basic Business
WDR
Support DWDR
Button
1 physical button
Network protocol
TCP/IP, IPv4, HTTP, RTP, RTSP, NTP
