SPECIFICATIONS
Input A / B
2 x 1/4" TS jacks, unbalanced
Impedance: 30 kΩ , unbalanced
Maximum input level: +20 dBu
Output A / B
2 x 1/4" TS jacks, unbalanced
Impedance: < 470 Ω, unbalanced
Maximum output level: +19.5 dBu
CV IN
1 x 1/4" TRS jack, 1 V/oct
CV input range: 0 V to +5 V
Sweep generator 1 / 2
Rate: 2 x rotary knobs
Control range: 0.1 Hz to 18 Hz, adjustable
Shape: 2 x rocker switch
 Sine / square wave, switchable
Phasor A
Sweep: 1 x rocker switch
Sweep generator 1 / control voltage, switchable
Depth: 1 x rotary knob
Feedback: 1 x rotary knob
Phasor B
Sweep sync: 1 x rocker switch
Normal / reverse phase, switchable
Sweep: 1 x rotary switch
 Sweep generator 1 / generator 2 / control voltage, switchable
Depth: 1 x rotary knob
Feedback: 1 x rotary knob
Power supply
External adapter
Power input
Standard 9 – 12 V DC, center negative, > 700 mA
Power consumption
6 W
Dimensions (H x W x D)
62.9 x 200 x 174.6 mm (2.48 x 7.87 x 6.87")
Weight
1.2 kg (2.7 lbs)
